Description
Overview
The PM-LV51100-3U-PRO LiFePO4 Battery offers exceptional energy storage solutions for a variety of applications, including off-grid power systems and renewable energy setups. With a nominal voltage of 51.2V and a capacity of 100Ah, this battery delivers a nominal energy of 5.12 kWh, ensuring reliable and efficient power storage. Designed for long-term performance, this battery has a cycle life of over 8000 cycles at 80% DOD, providing consistent and high-quality energy over time.
Key Features
- High Capacity & Energy Output: With a nominal voltage of 51.2V and a 100Ah capacity, the PM-LV51100-3U-PRO offers a total energy of 5.12 kWh, making it ideal for medium-to-large energy storage systems.
- Long Cycle Life: The battery is engineered for durability, boasting over 8000 cycles at 80% DOD and over 9000 cycles at 60% DOD, ensuring long-lasting performance for various energy applications.
- Wide Temperature Range: The PM-LV51100-3U-PRO is capable of operating within a wide temperature range, from -20°C to 60°C during discharging and 0°C to 60°C during charging, making it suitable for various environments.
- Advanced BMS Protection: Equipped with a JBD BMS, the battery includes multiple protections, such as overcurrent, overcharge, overdischarge, overload, overvoltage, low voltage, and overtemperature, ensuring safe and reliable operation.
- Scalable Energy Storage: The battery supports up to 16 units in parallel, with the potential to expand up to 64 units, making it a versatile choice for systems that require scalable energy storage.
- Reliable Communication Features: It supports RS485 and CAN-bus communication protocols for easy integration into existing monitoring and control systems.
- Optional Upgrades: The PM-LV51100-3U-PRO comes with various optional upgrades, including Bluetooth, App control, WiFi, SNMP, PC Monitoring Software, GPS, and more for enhanced control and monitoring.
- Certified Safety Standards: This battery is certified with UL 1642, UL 1973, IEC 62619, IEC 62133, CE, RoHS, and UN38.3, ensuring it meets global safety and environmental standards.
Product Description
The PM-LV51100-3U-PRO LiFePO4 battery is a high-performance energy storage solution designed to meet the needs of renewable energy, off-grid applications, and telecom systems. With a compact form factor (440 x 440 x 136 mm) and a weight of approximately 41 kg (90.4 lbs), this battery is easy to integrate into various systems while providing significant energy storage capacity.
Built using LiFePO4 (Lithium Iron Phosphate) cells, this battery offers exceptional thermal stability, safety, and long cycle life, making it ideal for both commercial and residential energy systems. The battery operates efficiently with a max charge voltage of 58.4V and a discharge cut-off voltage of 40V, ensuring optimal performance during both charging and discharging cycles.
With a design life of 20 years, the PM-LV51100-3U-PRO is built to last, offering over 8000 deep discharge cycles at 80% DOD and more than 9000 cycles at 60% DOD. The battery’s IP21 rating indicates it is protected against dust ingress and limited water exposure, ensuring its durability in most environments.
Additional Features
- Compact & Robust Design: The battery’s compact size (440 x 440 x 136 mm) and metal shell provide durability and ease of installation in various setups, while maintaining a high energy density for maximum power storage.
- Long-Term Reliability: With a cycle life of over 8000 cycles at 80% DOD, the PM-LV51100-3U-PRO provides a reliable and long-term solution for continuous power supply in both residential and industrial applications.
- Battery Management System (BMS): The integrated JBD BMS ensures the safety and performance of the battery by providing protection from overcharge, overdischarge, overcurrent, and temperature extremes. This smart BMS optimizes the battery’s performance and prolongs its lifespan.
- Scalable Energy Storage: The ability to connect up to 16 batteries in parallel, with an option to scale up to 64, makes the PM-LV51100-3U-PRO ideal for large-scale energy storage systems.
- Global Certifications: The PM-LV51100-3U-PRO is certified to meet international safety and environmental standards, including UL 1642, UL 1973, IEC 62619, and IEC 62133, offering peace of mind regarding quality and safety.
Warranty & Support
To ensure complete customer satisfaction, the PM-LV51100-3U-PRO LiFePO4 Battery comes with a comprehensive 10-year warranty, protecting against defects in manufacturing and ensuring long-term performance. Our dedicated support team is available to assist with installation, troubleshooting, and system integration.
Why Choose the PM-LV51100-3U-PRO LiFePO4 Battery?
For customers seeking a high-performance, durable, and scalable energy storage solution, the PM-LV51100-3U-PRO LiFePO4 battery is an excellent choice. It offers reliable energy storage with long cycle life, robust safety features, and the ability to integrate into a variety of renewable energy systems. With extensive customization options and support for various inverters, this battery provides flexibility for both residential and commercial applications. Choose the PM-LV51100-3U-PRO for an efficient and reliable energy storage solution backed by industry-leading technology.
How Does the 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO Enhance Energy Storage?
The 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO is a high-performance, modular lithium iron phosphate battery designed for scalable, safe, and efficient energy storage. It offers advanced safety features, compatibility with multiple inverters, and intelligent monitoring, making it ideal for renewable energy, data centers, and industrial power backup applications.
What Are the Technical Specifications of the 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO?
This battery features a nominal voltage of 51.2 volts and a capacity of 100 ampere-hours, delivering 5.12 kWh of usable energy. It supports a maximum continuous discharge current of 100A and a peak current up to 150A for short bursts. The battery weighs approximately 46 kg and fits into a compact 3U rack space with IP20 protection, designed for natural ventilation and flexible installation.
Technical Specifications Chart
| Specification | Value | Unit | Description |
|---|---|---|---|
| Nominal Voltage | 51.2 | V | Standard operating voltage |
| Nominal Capacity | 100 | Ah | Battery capacity |
| Usable Energy | 5.12 | kWh | Total energy storage |
| Max Continuous Discharge | 100 | A | Sustained current output |
| Peak Discharge Current | 150 | A | Short-term high current output |
| Weight | 46 | kg | Battery weight |
| Dimensions (WxHxD) | 538x483x136 | mm | Physical size |
| Protection Level | IP20 | – | Dust protection, no water ingress |
How Does the PRO Model Differ from Standard 51.2V 100Ah Batteries?
The PRO model integrates enhanced Battery Management System (BMS) capabilities, including module-level auto-balancing, advanced thermal monitoring, and built-in breaker on/off switches for safety and ease of use. It supports up to 63 units in parallel, enabling massive scalability up to 322 kWh, and offers optional communication interfaces such as RS232, RS485, CAN, WiFi, and Bluetooth for real-time monitoring and control.
How Does Modular Design Enhance Battery Expansion and Scalability?
The modular design allows individual battery units to be connected in parallel seamlessly, enabling users to scale their energy storage capacity according to demand. This flexibility reduces upfront investment and facilitates maintenance by isolating faulty modules without shutting down the entire system. The PRO battery’s BMS ensures balanced charging and discharging across all modules, optimizing performance and longevity.
What Safety Features Are Integrated into the PRO Battery?
Safety is paramount in the PRO battery, with features including:
-
No thermal runaway or fire propagation risk due to stable LiFePO4 chemistry.
-
Built-in BMS with overcharge, over-discharge, overcurrent, short circuit, and temperature protections.
-
Breaker on/off switch for safe manual disconnection.
-
Natural ventilation design to prevent overheating.
-
UL standardized battery modules ensuring compliance with international safety standards.
How Compatible Is the PRO Battery with Various Inverters and Systems?
The PRO battery is compatible with over 20 inverter brands and models, supporting both new installations and retrofits. Its communication protocols (RS232, RS485, CAN, optional WiFi and Bluetooth) enable seamless integration with energy management systems, allowing users to monitor battery status, control charge/discharge cycles, and optimize energy use.
What Are the Typical Applications of the 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO?
This battery is widely used in:
-
Data centers and server rooms for uninterrupted power supply.
-
Residential and commercial solar energy storage systems.
-
Telecom infrastructure backup power.
-
Industrial automation and machinery power backup.
-
Off-grid and emergency power systems.
What Is the Expected Cycle Life and Warranty of the PRO Battery?
The PRO battery boasts a cycle life exceeding 6,000 cycles at 90% depth of discharge, translating to over 15 years of operational life under normal conditions. It comes with a 10-year warranty backed by LiFePO4-Battery-Factory, ensuring long-term reliability and support.
How Does the PRO Battery Support Renewable Energy and Off-Grid Systems?
Its fast charge/discharge rates and high cycle life make the PRO battery ideal for smoothing intermittent renewable energy sources like solar and wind. The battery stores excess energy generated during peak production and delivers it during demand peaks or outages, enhancing energy independence and grid stability.
What Are the Recommended Operating and Maintenance Conditions?
Optimal operation occurs within a charging temperature range of 0 to 55°C and discharging from -20 to 55°C. The battery should be stored between 0 and 33°C to preserve longevity. Maintenance includes regular visual inspections, monitoring via the BMS, and ensuring proper ventilation to avoid overheating.
What Communication and Monitoring Capabilities Does the PRO Battery Offer?
The PRO battery supports multiple communication interfaces (RS232, RS485, CAN, WiFi, Bluetooth) enabling real-time monitoring of voltage, current, temperature, state of charge, and health. This data empowers users to optimize performance, schedule maintenance, and integrate with smart energy management platforms.
How Does LiFePO4-Battery-Factory Customize Solutions for Clients?
LiFePO4-Battery-Factory specializes in tailored battery solutions, offering custom voltage, capacity, and form factor configurations. Their expert team collaborates closely with clients to design and manufacture batteries that fit unique operational requirements, ensuring seamless integration, enhanced safety, and maximum efficiency.
Lithium Battery Expert Views
“At LiFePO4-Battery-Factory, the 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO exemplifies our commitment to innovation and reliability,” says a senior expert. “Its modular scalability, advanced BMS, and robust safety features make it a superior choice for critical energy storage applications. We pride ourselves on delivering customized solutions that empower clients worldwide to achieve energy independence and operational excellence.”
Conclusion
The 51.2V 100Ah Rack-mounted LiFePO4 Battery PRO is a cutting-edge energy storage solution combining high capacity, modular design, and advanced safety features. Its compatibility with diverse systems, long cycle life, and intelligent monitoring capabilities make it ideal for a wide range of applications, from data centers to renewable energy storage. Supported by LiFePO4-Battery-Factory’s expertise and warranty, this PRO battery offers a future-ready, scalable, and reliable power solution.
